PRO series helps users work smarter by delivering an efficient and productive experience. Featuring stable functionality and high-quality assembly, PRO series motherboards provide not only optimized professional workflows but also less troubleshooting and longevity.
Detecting CPU & GPU temperatures and automatically adjusting fan duty of system fans to a proper value by adopting MSI AI ENGINE.
MSI motherboards let you manage speeds and temperatures for all your system and CPU fans. Total Fan Control allows you to check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for the CPU and motherboard, which will adjust the fan speeds automatically.
Ran into trouble? Onboard LEDs for key components will indicate the source of the problem so you know exactly where to look to get it up and running again.
MSI PCI Express Steel Armor slots are secured to the motherboard with extra solder points and support the weight of heavy graphics cards. When every advantage in games counts, Steel Armor shields the point of contact from electromagnetic interference.
Double ESD protection doubles up the grounding layer around the mounting holes, preventing static discharge surges from damaging the motherboard.
Stay connected with Intel® LAN, optimized for stable internet throughput and ideal for championship-level online plays.
MSI PRO Series motherboards support all the latest storage standards, which allows users to connect any ultra-fast storage device. Higher efficiency makes your work easier.
USB 3.2 GEN 1
Transferring lots of data, music, and movies over USB is easier. USB 3.2 Gen 1 ports are ready in both front and rear IO provides a wide variety of options to connect your USB 3.2 Gen 1 devices.
MSI lightning Gen 4 PCI-E is the latest and the fastest PCI-E data transfer solution with 64GB/s of transfer bandwidth that has doubled compared to its previous generation. PCIe 4.0 maintains both backward and forward compatibility with older and newer specifications. Optimized by steel armor design, your motherboards can support the weight of heavy graphics cards.
MSI conducts thorough memory testing with the most popular memory brands under extreme conditions to ensure your system runs stable no matter what. Our memory partners include brands like Corsair, Crucial, Kingston, G.Skill, and many more to optimize memory modules and configurations.
Core Boost technology combines MSI's premium layout and optimized power design which allows for faster and undistorted current delivery to the CPU at pinpoint precision. Not only supports multi-core CPU, but also creates the perfect conditions for your CPU overclocking.
CPU (MAX SUPPORT) |
i9 |
SOCKET |
1700 |
CHIPSET |
Intel® H610 Chipset |
|
DDR4 MEMORY |
3200(MAX) / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz |
|
MEMORY CHANNEL |
Dual |
|
DIMM SLOTS |
2 |
MAX MEMORY (GB) |
64 |
|
PCI-E X16 |
1 |
|
PCI-E X1 |
1 |
|
SATAIII |
4 |
|
M.2 SLOT |
1 |
|
TPM (HEADER) |
1 |
|
LAN |
1x Realtek® 8125B 2.5Gbps LAN controller |
|
2(Gen 1, Type A) |
|
2(Gen 1, Type A) |
|
USB 2.0 PORTS (FRONT) |
4 |
|
USB 2.0 PORTS (REAR) |
2 |
|
SERIAL PORTS(FRONT) |
1 |
|
AUDIO PORTS (REAR) |
Realtek® ALC897 Codec |
|
DISPLAYPORT |
1 |
|
VGA |
1 |
|
HDMI |
1 |
|
DIRECTX |
12 |
|
FORM FACTOR |
MATX |
|
OPERATING SYSTEM |
Support for Windows® 10 64-bit |
