N.B. Image may vary with product
Power Evolved
Cooler Master presents the MWE Bronze V3 230V, the upgraded version of the MWE Bronze featuring ATX 3.1 support, high temperature resilience, a smart DC-to-DC + LLC circuit design, a quiet HDB fan, 80 Plus Bronze efficiency, an embossed cable, and a 5-year warranty.
ATX 3.1 Support
Compliant with ATX 3.1 to fully support a peak power 1.5 times higher than the rated maximum wattage, this unit is ideal for use with the 40 series GPUs.
All performance stats confirmed in 25°C ambient temperature testing.
Embossed Cable
An embossed cable texture provides a softer and overall improved grip with a pleasing aesthetic.Quiet HDB Fan
A hydrodynamic bearing fan delivers long-lasting quiet and effective cooling.
All performance stats confirmed in 25°C ambient temperature testing.
Certified Efficiency
The MWE Bronze V3 230V is certified to achieve more than 88% efficiency at typical loads.
All performance stats confirmed in 25°C ambient temperature testing.
High Temperature Resilience
A 40°C operating temperature allows for pushing your machine to the limits.
PSU Calculator
Need help choosing the right power supply for your ? Try out our comprehensive and easy-to-use PSU calculator.
| Specification | Details |
|---|---|
| Model | MPE-5501-ACABW-3B |
| Series | MWE Bronze Series |
| Category | 500 to 750W |
| Watts | 550W |
| Form Factor | ATX |
| ATX Version | ATX 12V Ver. 3.1 |
| Modular | Non Modular |
| PFC | Active PFC |
| Input Voltage | 200&ndash240V |
| Input Current | 5A |
| Input Frequency | 50&ndash60Hz |
| Dimensions (L × W × H) | 140 × 150 × 86 mm / 5.5 × 5.9 × 3.4 inch |
| Fan Size | 120mm |
| Fan Bearing | HDB |
| Efficiency | >88% @ Typical Load |
| 80 PLUS Rating | 80 PLUS Bronze EU 230V |
| 80 Plus Efficiency | Bronze |
| ErP 2014 Lot 3 | Yes |
| Operating Temperature | 0&ndash40°C |
| Power Good Signal | 100&ndash150 ms |
| Hold Up Time | >16 ms |
| MTBF | >100,000 Hours |
| Protections | UVP / OVP / OPP / OTP / SCP |
| Regulatory | TUV, CE, FCC, CCC, EAC, RCM, UKCA, RoHS 2.0 / BIS, KC (region dependent) |
| ATX 24-Pin Connectors | 1 |
| EPS 8-Pin / 4+4-Pin Connectors | 2 |
| SATA Connectors | 6 |
| Peripheral 4-Pin Connectors | 3 |
| PCI-e 6+2-Pin Connectors | 2 |
| Warranty | 5 Years |
