N.B. Image may vary with product
i2 is a new generation of high performance, multifunctional PDA launched by iMACHINE, with fully performance and experience feeling. The screen is 5.5inch HD, which is portable and comfortable to hold. It has more stable connection, richer match, super industrial protection performance, fully meet the needs of industrial applications.
i2 is perfectly suit to many scenarios, such as logistics, express, warehouse inventory, manufacturing, retail e-commerce, public utilities, asset management etc. The goal is to improve the operation and management level with efficiently data collection.
|
Performance Characteristics |
CPU |
ARM Cortex-A53, Octa-Core 2.0GHz/2.3GHz |
|
|
OS |
Android 11.0/13.0 |
||
|
Memory |
4GB RAM+64GB ROM (optional) |
||
|
SIM Card Slot |
2 x Nano SIM Cards |
||
|
Storage Expansion |
1 x Micro SD Card,（SDHC、SDXC supported, up to 512GB） |
||
|
Physical Characteristics |
Display |
5.5&rdquoHD+ IPS 720×1440p, Industrial grade Capacitive Multi-Touch |
|
|
Battery |
Removable Lithium Battery, 3.85V/5000mAh |
||
|
Backup battery |
Support hot swap the battery, device keep working (optional) |
||
|
Dimensions |
157.8mm×75.5mm×14.9mm |
||
|
Weight |
250g (with battery) |
||
|
Ports |
1×USB Type C ( support USB 2.0, OTG, Fast charging) |
||
|
Expansion Ports |
2 Pin Rear POGO PIN：Trigger key 2 Pin Bottom POGO PIN：Charging port |
||
|
Keys |
1×Power key , 1×Volume(+/-) key, 1×Function key, 2×Scan keys |
||
|
Prompts |
Vibration，Multi-Color LEDs，Audio |
||
|
Audio |
Speaker, Receiver, Dual Microphones (noise reduction) |
||
|
Sensor |
G-Sensor, Light Sensor, Proximity Sensor E-compass (optional), Gyroscope (optional) |
||
|
Data Capture |
Scan Engine |
MinDeo: ME8601/ME5066 Newland: CM60 Honeywell: N6703/N6603/HS7 Zebra: SE4770/SE4720/SE4710 |
|
|
Camera |
Rear camera: 13 Megapixels, flash support, auto focus Front camera: 5 Megapixels, fixed Focus |
||
|
NFC |
Support ISO15693, ISO14443A/B, Mifare card, Felica card |
||
|
Network Connection |
Wireless WAN |
Eurasian |
4G:B34/B38/B39/B40/B41/B1/B3/B5/B7/B8/B20/B28A/B28B 3G:B1/B5/B8/B34/B39 2G: 850/900/1800/1900 |
|
American |
4G:B38/B41/B1/B2/B3/B4/B5/B7/B12/B17/B19/B26/B28A/B28B/B66 3G: B1/B2/B4/B5/B8 2G: 850/900/1800/1900 |
||
|
Wireless LAN |
2.4GHz & 5GHz dual-band Wi-Fi, support 802.11r fast roaming IEEE 802.11 ac/a/b/g/n/ax ready/d/e/h/i/j/k/r/v/w |
||
|
Wireless PAN |
BT5.0 + BR/EDR + BLE |
||
|
GPS |
GPS L1, GLONASS, Beidou, Galileo |
||
|
User Environment |
Operating Temp. |
-20℃ ～+60℃ |
|
|
Storage Temp. |
-40℃ ~ +70℃ |
||
|
Charging Temp. |
0℃ ~ +45℃ |
||
|
Humidity |
5%-95% RH (No condensation) |
||
|
Sealing Standard |
IP68 |
||
|
Spec. |
1.5m |
||
|
Tumble Spec. |
1000 drops (500 cycles) 0.5m tumbles at room temperature |
||
|
ESD |
±15 kV Air Discharge, ±8 kV Direct Discharge |
||
|
Accessories |
Standard |
Power Adaptor×1, USB Cable×1, Battery×1 |
|
|
Optional |
Lanyard, Hand strap, Cradle, Pistol Grip, Protective Case, Four-battery Charger |
||
